Inner Tube: Synthetic rubber with oil, weather, and abrasion resistance Reinforcement Layer: Two layers of high tensile braided textile Outer Cover: Synthetic rubber with oil, weather, and abrasion resistance Temperature Range: -40℃ – +120℃ Working Pressure: 375 to 1500 psi Surface: Wrapped or smooth surface Product Description Hydraulic Rubber Hose SAE100 R3 is designed to transfer petroleum-based hydraulic fluids or oils under low-range pressure. It comprises the inner tube, reinforcement layer, and outer cover. The inner tube is made of oil-proof synthetic rubber, which does not react with oil or water-based hydraulic fluids. The reinforcement comprises two high-tensile layers with braided textile material, which keeps the hydraulic hose lightweight and flexible. The outer cover is also made of synthetic rubber with oil, weather, and corrosion resistance, providing the hose with an extended service life. Features And Benefits Oil, weather, abrasion, and corrosion resistant High tensile strength, exceptional flexibility, and light in weight Able to work under extensive temperatures ranging from -40°C to +120°C It complies with stringent industry standards such as REACH and RoHS Hydraulic Rubber Hose Application The hydraulic hose is mainly used for petroleum-based and water-based hydraulic fluids and pneumatic applications. Technical Data Sheet

DN	Hose ID		Hose O.D	Max. Working Pressure		Min. Burst Pressure		Min. Bend Radius
	inch	mm	mm	Mpa	Psi	Mpa	Psi	mm
5	3/16"	4.8	12.7	10.5	1520	42	6090	75
6	1/4"	6.4	14.4	8.7	1260	35	5080	75
8	5/16"	7.9	17.5	8.4	1220	34	4930	100
10	3/8"	9.5	19.0	7.8	1130	31	4500	100
13	1/2"	12.7	23.8	7.0	1000	28	4060	125
16	5/8"	15.9	27.0	6.1	890	24	3480	140
19	3/4"	19.0	31.8	5.2	760	21	3050	150
25	1"	25.4	38.0	3.9	570	16	2320	205
32	1 1/4"	31.8	44.4	2.6	380	10	1450	250
